Product Features
• Effective for fast freeze drying of any samples
• HyperVAC-MAX empowered by HyperCOOL guarantees capacity and performance at higher level.
• HyperCOOL by itself, when equipped with manifolds or chambers, becomes a versatile freeze dryer.
• Extended applications for concentrating wider range or larger volume of solvents.
• The compatible vacuum rotary vane pump generates vacuum down inside the chamber.
• Up to 8 external bottles can be accommodated by the manifolds of HyperCOOL.
• Automatic De-Vac and De-Ice functions installed
• HyperVAC-MAX empowered by HyperCOOL guarantees capacity and performance at higher level.
• HyperCOOL by itself, when equipped with manifolds or chambers, becomes a versatile freeze dryer.
• Extended applications for concentrating wider range or larger volume of solvents.
• The compatible vacuum rotary vane pump generates vacuum down inside the chamber.
• Up to 8 external bottles can be accommodated by the manifolds of HyperCOOL.
• Automatic De-Vac and De-Ice functions installed
Applications
• Study and QC of dried foods like dried fruits, meats, etc.
• Stock of bacteria, virus, fungi, etc.
• Seed preservation of plants or mushrooms
• Improved preservation of flowers and dry display study
• Pharmaceutical study and production
• Research and production of vaccine and antidote
• Tissue or cell preparation for EM analysis
• Medical research
• Stock of bacteria, virus, fungi, etc.
• Seed preservation of plants or mushrooms
• Improved preservation of flowers and dry display study
• Pharmaceutical study and production
• Research and production of vaccine and antidote
• Tissue or cell preparation for EM analysis
• Medical research
Technical Specifications
|
Model
|
HC3110
|
|
Ultimate chamber temp (at RT) (℃)
|
-110
|
|
Chamber volume (L)
|
4
|
|
Trap (Chamber) size (Ø x L)
|
165 x 202
|
|
ICE condensing capacity (kg)
|
3
|
|
ICE condensing performance (kg/day)
|
2.5
|
|
Compressor
|
1/3 HP x 2
|
|
Refrigerant
|
R507/R1150
|
|
Digital Readout
|
Time, Temperature
|
|
Function
|
Keylock, Defrost, Vacuum, Time
|
|
Power requirement (Resting, VA)
|
819
|
|
Power supply(V/Hz)
|
220 V/50~60 Hz (110 V optional)
|
|
Dimension (W x D x H, mm)
|
400 x 660 x 570
|
|
Weight (kg)
|
72
|
|
Cat. No.
|
HHC-3110 (HHC-3110-110)
|
