Programmable model (OFC-P/PH)
for intelligent program control
- 10 programs available for temperature ramp up and dwell control.
- 10 steps per a program and 99 hours 59 minutes per a step.
- Stored programs are easily linkable.
- Programs can be repeated up to 99 cycles.
- Pre-heating and heating time are settable before program starts.
Class 100 cleanliness is achieved by HEPA filter.
- 0.3 μm and larger particulates are removed with 99.97% efficiency, leak-tight HEPA filter which satisfying class 100.
- Easy HEPA filter condition check by a built-in front differential pressur.
- Real time monitor of HEPA filter is available.
– Optional digital differential pressure gauge let users know when filter needs replacement.
Performance
- Rapid heating performance up to max. 300°C (for OFC-HP)and max. 200°C (for OFC-P)
- Microprocessor PID control.
- Three point temperature calibration / Automatic tuning.
- Forced air convection generated by two noiseless and powerful sirocco fans ensures optimal air circulation, temperature uniformity, and short heat-up time.
- Adjustable dual slide vents for inner vapor circulation.
- Energy efficiency is achieved thanks to optimization of the insulation system.
– Even if the unit is operating at max. temperature, the surface of the unit doesn’t allow high temperatures.
Convenience
- Optimum model selection is available according to two different types of control panel.
– Intuitive touch screen LCD controller with easy icons and logical menus. (for OFC-P/HP) - Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.)
- Convenient presetting function for 3 most commonly used temperature settings.
- Rounded inner chamber corners for easy cleaning and optimal airflow.
- Corrosion-resistant incoloy sheath heating element and stainless steel interior.
- Threefold tempered-glass window provides clear inside view of the chamber. (optional)
- USB port and RS-232 port for external control and data collection.
- Casters for easy mobility during installation or relocation.
Safety
- Automatic run after power interruption.
- Over-current protection.
- Triple independent temperature monitor system.
-Temperature deviation alarm. (High/Low)
-Electronic temperature limiter.(High/Low)
-Mechanical over-temperature limiter.(High) - Alarms for open door status, temperature sensor error and temperature deviation.
- Keypad lock function prevents accidental changes during operation.
