Specifications
| Total Magnification | 40x, 100x, 400x, 1000x. |
| Viewing Head | Trinocular Siedentopf viewing head with 30° inclined binocular eyepiece with interpupillary adjustment 50mm to 75mm. Left eyetube has diopter adjustment of /-5. Beam splitter has 100/0 or 20/80 positions for camera. |
| Eyepiece | Widefield 10x eyepieces / FN 18mm. Diopter on left eyepiece with adjustment of /-5. |
| Objectives | DIN Standard 4x Plan Achromat, cover-slip corrected, parfocalled, parcentered, color-coded. |
| DIN Standard 10x Plan Achromat, cover-slip corrected, parfocalled, parcentered, color-coded. | |
| DIN Standard 40x Plan Achromat, cover-slip corrected, parfocalled, parcentered, color-coded, retractable. | |
| DIN Standard 100x Plan Achromat, cover-slip corrected, parfocalled, parcentered, color-coded, retractable, oil immersion. | |
| Nosepiece | Quad objective turret is ball-bearing mounted for smooth, precise positioning of objectives, features textured rubber knurling for easy grip. Mounted in reverse position to facilitate ease in changing slides. |
| Body | Rugged metal parts are locked-on for student-proof features. Glass optics. |
| Stage | Large 140mm x 132mm stage (5.5″ x 5.2″), with professional quality, built-in, low profile, ball-bearing mounted mechanical specimen holder with low-position coaxial controls, 76mm (X) by 50mm (Y) movement with graduations of 0.1mm. |
| Condenser | 1.25 N.A. Abbe condenser has rack & pinion focusing and iris diaphragm with preset positions and filter holder. |
| Focusing | Coaxial coarse and fine focusing controls, fine focus graduations of 0.002mm, 25mm vertical travel range, tension adjustment on coarse focus knob, and safety rack stop to prevent damage to objective lenses and slides. |
| Illumination | 3W LED with variable rheostat control and on/off switch.110~240V power supply. LED bulb is rated to 20,000 hours of use. Includes four AA rechargeable batteries and recharger. Use plugged in or cordless. |
| Camera | HD 720p camera. Live resolution 1280 x 720 pixels. 1 megpixel image capture resolution. Video capture resolution 720P (HD). USB output. Live image at 720p / 30 fps. Image capture to SD card or USB computer image capture. Camera controls for exposure, gain, white balance, color adjustment, sharpness. Includes mouse for on-screen controls. Includes software for image management, measurement. USB connection to Windows or MAC OSX. (Note: measurement features will not work on a MAC). HDMI direct connection to monitor. If using an alternative HDMI monitor, you must be able to set the monitor resolution to 1280 x 720. Includes 0.35x c-mount adapter for connection. |
| Monitor | 12″ LCD HDMI monitor, 720p. LED backlight. Monitor mounts directly to HD camera and includes 110~240V power cord and HDMI cable. |
| Dimensions | 20″ H x 8.4″ W x 13.8″ D |
| Weight | 17 lbs. |
| Included | Dust cover, blue filter, extra fuse, immersion oil, c-mount adapter. |
| Warranty | Microscope 5-year limited warranty, excluding bulb, cord and fuse. Tablet camera 1 year warranty. |
